Since 2005,We Focus on Machinery Production

10 Ton Overhead Crane Solution

Now you can acquire a customized 10 Ton overhead crane that suits your construction, manufacturing, warehousing, or other industrial projects!

10 Ton Overhead Crane Application Areas

Some of the most suitable areas to use our 10 Ton overhead crane solutions include:

  • Construction Site:  For efficient lifting and moving of heavy construction materials.
  • Manufacturing Facilities:  To facilitate the lifting and moving of materials and finished products.
  • Heavy Machinery Maintenance:  Lifting and moving heavy machines or machine components at repair stations.
  • Mining Industry:  Efficient lifting and moving of heavy mining materials or machinery.
  • Power Industry:  Handling of heavy equipment or components within the power

Description

10 Ton Overhead Cranes: 2 Ultimate Options

10 Ton Light Double Beam Overhead Crane

Our CE and ISO-certified light 10 Ton overhead crane is a cost-effective solution designed to safely, efficiently, and precisely lift and move your heavy industrial loads.

Spanning up to 49 meters and with a maximum lifting height of 30 or 40 meters, this double

Winch 10 Ton Overhead Crane

With our heavy-duty winch 10 Ton double beam overhead crane, you have the ultimate power to safely lift and move your heavy industrial loads or equipment weighing up to 10 tons.

The crane has a maximum span of 49 meters with lifting heights of 30 to 40 meters, which makes it cost-effective for handling goods in a wide construction location or any industrial setting.

10 Ton Light Double Beam Overhead Crane.

Key Benefits and Features:

  • A cost-effective solution capable of lifting heavy industrial loads or materials
  • Controllable Speed ​​with remote operation options for enhanced safety
  • Comes with compact and energy-efficient European-style electric wire rope hoist
  • Equipped with remote control options for enhanced safety during operation
  • Boasts bridge crane features for guaranteed operational stability
  • Impressive span length of up to 49 meters for enhanced load-handling
  • Customizable to fit your industrial needs
  • Comes with the necessary support services you may need

Specifications:

Descriptions Details
Key Components Gearbox, Motor, Frequency Converter
Origin Henan , China
Warranty Period 1 Year
Tare Weight 5000 kg
Crane Design Bridge/overhead Crane
Load-Lifting Range 5 to 100 Tons
Span Range 0-49M
Product Name Light Double Beam Overhead Crane
Application Construction Hoist
Maximum Lifting Height 30M/40M
Lifting Speed 0.4-16m/min
Operating Speed 5-90m/min
Cross Traveling 3-30m/min
Type of Hoist European-style electric wire rope hoist
Operation Control Options Wireless remote control, cab control, handheld control
Certifications/Standards CE and ISO Certification standards

Winch 10 Ton Overhead Crane

Key Benefits and Features

  • Has a double-beam design for stable lifting of heavy industrial loads or equipment
  • Comes with its gearbox, motor, and frequency converter for smooth operation and control
  • Supports multiple remote control options for enhanced safety and efficiency
  • Comes with an energy-efficient European-style electric wire rope hoist.
  • Conforms to CE and ISO quality standards

Specifications:

Descriptions Details
Core Components Gearbox, Motor, Frequency Converter
Place of Origin Henan, China
Warranty Period 1 Year
Tare Weight 5000 kg
Crane Feature Bridge Crane
Lifting Load Range 5 to 360 Ton
Span Range 0-49M
Product Name Winch Double Beam Overhead Crane
Application Construction Hoist
Max Lifting Height 30M/40M
Lifting Speed 0.4-20m/min
Long Operating 5-90m/min
Cross Traveling 4-40m/min
Hoist European-style electric wire rope hoist
Control Options Wireless remote control, cab control, handheld control
Certifications CE, ISO
