30 Ton Overhead Crane Solution

Now you can choose the most suitable 30Ton overhead crane solutions for your construction, outdoor warehouse, and other industrial load-lifting projects!

Description

30 Ton Overhead Crane Specifications

Type Lifting Load Max Span Max Lifting Height Lifting Speed Control Options Applications
Light Overhead 30 Ton 5 to 100 Tons 0-49M 30M/40M 0.4-16m/min Wireless, Cab, Handheld Construction Hoist, Light Industrial Use
Winch Overhead 30 Ton 5 to 360 Tons 0-49M 30M/40M 0.4-20m/min Wireless, Cab, Handheld Heavy-duty Construction, Large Hoisting
30 Ton Gantry Crane Up to 320 Tons Up to 50M Up to 40M 0.4-16m/min Driver Room, Remote Control Subway Construction, Outdoor Warehouses, Railroads

30 Ton Light Overhead Cranes

Electric Hoist Crane Solutions for high-efficiency Load-lifting!

 30 Ton Light Overhead Crane

Our Light 30 Ton overhead crane is a an efficient heavy-duty crane designed for your construction and industrial load-handling projects.

Based on your project demands, this crane type that spans up to 49 meters, can be customized to lift upto 100 tons!

Winch 30 Ton Overhead Crane

Do you require a load lifting and pulling solution capable of handling up to 30 tons of load?

Our 30-ton winch overhead crane is a high-efficiency solution suitable for your heavy-duty construction site operations.

30 Ton Gantry Crane

Are you seeking an efficient outdoor 30-ton gantry crane solution for your construction or other industrial load-lifting project?

Our 30-ton Gantry Crane boasts a maximum span of 50 meters and speed control features for enhanced safety and performance efficiency.

Light Overhead Crane 30-Ton

Description Detail
Core Components Gearbox, Motor, Frequency Converter
Place of Origin Henan, China
Warranty 1 Year
Weight 5000 kg
Crane Feature Bridge Crane
Lifting Load 5 to 100 Ton
Span Range 0-49M
Product Name Light Double Beam Overhead Crane
Usage Construction Hoist
Max Lifting Height 30M/40M
Lifting Speed 0.4-16m/min
Operating Speed 5-90m/min
Cross Travelling 3-30m/min
Hoist European-style electric wire rope hoist
Control Options Wireless remote control, cab control, handheld control
Certifications CE, ISO

Key Benefits and Features

  • Load-lifting capacity of up to 30 tons
  • It comes with a gearbox, a motor, and a Frequency Converter for stable, efficient, and smooth lifting operations.
  • The crane can be customized to suit your project space or lifting height
  • It has an energy-efficient electric wire rope hoist for heavy-duty lifting requirements.
  • Complies with the CE and ISO standards.

Winch Overhead Crane 30 Ton

KRC ZLK Double Beam Crane Main technical parameters

Specification Detail
Core Components Gearbox, Motor, Frequency Converter
Place of Origin Henan, China
Warranty 1 Year
Weight 5000 kg
Crane Feature Bridge Crane
Lifting Load 5 to 360 Ton
Span Range 0-49M
Product Name Winch Double Beam Overhead Crane
Usage Construction Hoist
Max Lifting Height 30M/40M
Lifting Speed 0.4-20m/min
Long Operating 5-90m/min
Cross Travelling 4-40m/min
Hoist European-style electric wire rope hoist
Control Options Wireless remote control, cab control, handheld control
Certifications CE, ISO

Key Benefits and Features

  • Capable of lifting and pulling loads of up to 30 ton
  • It has a maximum lifting range of 30 to 40  meters
  • The crane can be customized to suit your load lifting requirements ranging from 5 to 360 Ton
  • It has a compact, energy-saving, and high-efficiency European-style wire rope hoist
  • The crane comes with 3 remote control options for enhanced safety and operational efficiency.

30 Ton Gantry Crane

Specifications

Description Details
Lifting Capacity Maximum 320 tons
Span Maximum 50 meters
Running Speed of Large Vehicle 3-30 m/min
Trolley Running Speed 4-40 m/min
Lifting Speed 0.4-16 m/min

Key Benefits and Features

  • Suitable for lifting heavy loads at construction sites
  • Robust weather-resistant design making it ideal for outdoor projects.
  • Has a large span span of up to 50 meters with a maximum lifting capacity of 30 tons.
  • It has speed control features to ensure smooth and efficient operation based on your project demands.
  • You can have the crane customized to lift loads of up to 320 tons.
